Simulating Meteorite Impacts in the Lab

The original Deutsches Elektronen Synchrotron press release can be read here.

A U.S.-German research team has simulated meteorite impacts in the lab and followed the resulting structural changes in two feldspar minerals with x-rays as they happened. The results of the experiments at the Deutsches Elektronen Synchrotron (DESY) and at the U.S. Department of Energy’s Advanced Photon Source (APS) at Argonne National Laboratory show that structural changes can occur at very different pressures, depending on the compression rate. The findings, published in Earth and Planetary Science Letters (published online in advance), will aid other scientists in reconstructing the conditions leading to impact craters on Earth and other terrestrial planets.

Meteorite impacts play an important role in the formation and evolution of Earth and other planetary bodies in our solar system. But the impact conditions, meaning the impactor size, velocity and the peak pressure and temperature, are usually determined long after the impact occurred from permanent changes in the rock forming minerals in the impact crater. To solve the puzzle of a meteorite impact, that is reconstructing the impact conditions from the rock record in an impact crater hundreds to millions of years after the event, requires scientist to reconcile observations from the field with the results of laboratory experiments.

Over the past decades, a classification scheme has been developed that ties impact conditions to pressure and temperature induced changes in rock forming minerals that can be found in typical rocks in impact craters. The feldspar-group minerals albite (NaAlSi3O8), anorthite (CaAl2Si2O8), and their mixture plagioclase (NaxCa1-xAl2-xSi2+xO8) are highly abundant in planetary crusts. Therefore, changes in these minerals with respect to pressure and temperature, such as the structural transformations or amorphization, that is, the loss of ordered crystal structure, are nowadays widely used as indicator for very large impacts.

However, for the feldspar group minerals, the reported values for the pressure conditions of the amorphization transition differ vastly if static or dynamic compression techniques are used. “These differences point to large gaps in our understanding of compression rate induced processes in minerals,” said Lars Ehm from Stony Brook University and Brookhaven National Laboratory, the principle investigator of the project. This has far-reaching implications for the interpretation of natural impact events based on the rock record with respect to the velocity, size and other properties of the meteorite.

The inner structure of minerals and other samples can be investigated with x-rays that are diffracted by the crystal lattice of a material. Form the characteristic diffraction pattern the inner structure of a sample can be determined. This technique has been used and refined since more than a century. It can now also be used to track dynamic processes.

“The emergence of new and very powerful x-ray sources such as PETRA III, the Advanced Photon Source, and the European X-ray Free Electron Laser in combination with the recent quantum leaps in x-ray detector technology provide us now with the experimental tools to investigate materials' response to measure the atomic structure at rapid compression conditions,” said Hanns-Peter Liermann, head of the Extreme Conditions Beamline P02.2 at DESY's x-ray source PETRA III, where some of the experiments were conducted.

“In our experiment we used gas- or actuator-controlled Diamond Anvil Cells to rapidly compress our samples, while we continuously collect x-ray diffraction patterns,” said Melissa Sims of Stony Brook University, lead author of the study. “This allows us to monitor the changes in the atomic structure during the complete compression and decompression cycle, and not only at the start and end of the experiment as in previous so-called recovery experiments.”

Utilizing time-resolved high-pressure experiments at the High Pressure Collaborative Access Team 16-ID-B x-ray beamline at the APS (an Office of Science user facility at Argonne) and the Extreme Conditions Beamline P02.2 at the Petra III x-ray source at DESY, the research team was able to obtain diffraction data and observe amorphization of albite and anorthite at different compression rates in the experiments. They compressed the minerals to a pressure of 80 gigapascals (GPa), corresponding to 80,000 times the atmospheric pressure. In the experiments, different compression rates, from 0.1 GPa per second (GPa/s) to 81 GPa/s, were used. “The results show that, depending on the rate of compression, the minerals undergo the amorphization transition at very different pressures,” Ehm said. “The increase in compression rate lead to a lowering of the observed amorphization pressure.” For example, at the lowest compression rate of 0.1 GPa/s, albite turned completely amorph at a pressure of 31.5 GPa while at the highest rate of 81 GPa/s this occurred already at 16.5 GPa.

“For these reasons, amorphization in plagioclase minerals is not likely to be an unambiguous standard to suggest specific peak pressures and temperatures conditions during meteorite impact,” said Ehm.

Further investigations are needed to fully understand the behavior of these minerals and to assess if impact conditions can be gauged against the structure of rock minerals.

See: Melissa Sims1*, Steven J. Jaret1, Eva-Regine Carl2, Brandon Rhymer1, Nadine Schrodt3, Vivien Mohrholz4, Jesse Smith5, Zuzana Konopkova6, Hanns-Peter Liermann7, Timothy D. Glotch1, and Lars Ehm1,8, “Pressure-induced amorphization in plagioclase feldspars: A time-resolved powder diffraction study during rapid compression,” Earth Plan. Sci. Lett. 517, 166 (2019). DOI: 10.1016/j.epsl.2018.11.038 (published online in advance)

Author affiliations: 1Stony Brook University, 2Albert-Ludwig-Universität Freiburg, 3Goethe-Universität Frankfurt, 4Friedrich-Schiller-Universität Jena, 5Carnegie Institution for Science, 6European XFEL GmbH, 7Deutsches Elektronen Synchrotron, 8Brookhaven National Laboratory

Correspondence: *

Hero image:

The research was partially supported by the U.S. National Science Foundation through grant EAR-1440095 and GEO-1107155. Additional support was provided by National Aeronautics and Space Administration through the Solar System Workings program under grant 80NSSC17K0765. M.S. is grateful for the support of the W. Burkhardt Turner Fellowship. L.E., M.S., and B.R. acknowledge the support from the travel award by the Joint Photon Science Institute at Stony Brook University. T.G. acknowledges support from the Remote, In Situ, and Synchrotron Studies for Science and Exploration (RIS4E) node of NASA’s Solar System Exploration Research Virtual Institute (SSERVI). DESY is a member of the Helmholtz Association (HGF). High Pressure Collaborative Access Team operations are supported by U.S. Department of Energy (DOE)-National Nuclear Security Administration under Award No. DE-NA0001974 and DOE-Basic Energy Sciences under Award No. DE-FG02-99ER45775, with partial instrumentation funding by NSF. The Advanced Photon Source is a U.S. DOE Office of Science User Facility operated for the DOE Office of Science by Argonne National Laboratory under Contract No. DE-AC02-06CH11357.
